FRP Compression Molding Equipment
Core System Configuration
1. Hydraulic Press Module
Clamping Force: 100-3,000 tons (modular expansion available)
Platen Size: Up to 2.5×4.5m (heated platens with 5-zone PID control)
Parallelism: Maintains ≤0.05mm/m across full stroke
2. Advanced Control System
10-stage curing profile with pressure/temperature interlocks
Real-time viscosity monitoring via dielectric sensors
Automatic flash removal with servo-driven trim tools
3. Material Handling Options
Robot-loaded prepreg stacks (±1mm positioning accuracy)
BMC/SMC automatic feeders (50kg/min dosing capacity)
Technical Specifications
Model | LX-CM300 | LX-CM800 | LX-CM1500 |
Clamping Force | 300T | 800T | 1500T |
Daylight | 600mm | 1000mm | 1500mm |
Platen Temp. | 200°C | 220°C | 250°C |
Cycle Time | 90-180s | 120-300s | 180-420s |
Energy Consumption | 18kW | 45kW | 75kW |
Key Process Advantages
✔ Ultra-Precise: Linear guides with 0.005mm repeat positioning accuracy
✔ Multi-Material: Handles CFRP, GFRP, SMC, and BMC composites
✔ Quality Traceability: Blockchain-enabled production data logging
Supported Manufacturing Processes
High-Pressure Resin Transfer Molding (HP-RTM)
Direct Long Fiber Thermoplastic (D-LFT)
Sheet Molding Compound (SMC) Compression
Automation Integration
Preheating Stations: Infrared or microwave options
Post-Curing Ovens: 3D laser-scanned dimensional verification
Defect Detection: AI-based visual inspection system
Certifications: CE Machinery Directive, ISO 13849 PLd, UL 508A
Industry-Specific Solutions
◼ Automotive: Battery trays, structural cross-beams
◼ Electrical: 35kV insulator bushings, switchgear components
◼ Consumer: High-gloss appliance panels with Class A surfaces
Lead Time: 16 weeks for standard models, 20-24 weeks for customized cells
FRP Compression Molding Equipment Customer Evaluation
FRP Compression Molding Equipment FAQ
-
What is FRP compression molding equipment?
It is machinery designed to shape Fiber Reinforced Plastic (FRP) materials under high pressure and temperature to produce precise, durable molded products.
-
What are the advantages of FRP compression molding?
Advantages include high dimensional accuracy, smooth surface finish, fast production cycles, strong and lightweight finished parts, and reduced material waste.
-
What industries use FRP compression molding equipment?
Widely used in automotive, construction, electrical components, aerospace, and industrial equipment manufacturing.
-
Can the equipment handle large or complex shapes?
Yes, with appropriate molds and pressure settings, the machine can produce complex, large, or custom FRP components efficiently.
